Professional Touch Solution｜IP65 Rating｜1 Million+ Operation Life
The BSD-5010-R5 tactile-dome servo controller membrane switch delivers precision control for industrial applications. Featuring a durable matte surface finish with anti-glare properties, this switch panel provides optimal visibility in various lighting conditions. The high-quality tactile dome mechanism ensures crisp, responsive feedback with an actuation force of 180±50gf, offering consistent performance through 1 million+ operations.
Key advantages include:
IP65-rated protection against dust, moisture, and environmental contaminants
Customizable backlighting options (LED/EL) for enhanced visibility
Precision servo control with ±0.5mm actuation point accuracy
Chemical-resistant overlay withstands cleaners and solvents
EMI/RFI shielding available for sensitive electronic environments
The panel's flexible flat cable (PFC) interface ensures reliable connections while saving space. Ideal for CNC equipment, robotics, and industrial automation systems requiring durable, high-performance control interfaces. OEM customization available for graphic overlays, connector types, and specific operational requirements.
The BSD-5010-R5 industrial-grade membrane switch delivers precision control for servo systems with its high-performance tactile dome technology. Featuring:
1. 1M+ operation lifespan
2. IP65 dust/water resistance
3. ±0.5mm actuation accuracy
4. 180±50gf tactile feedback
5. EMI/RFI shielding options
Our matte-finish switch panel is engineered for CNC machines, robotics, and automation equipment. Customizable with:
• LED/EL backlighting
• Chemical-resistant overlays
• Flexible PFC connectivity
Trusted by OEMs worldwide for:
1. Reliable servo control
2. Harsh environment operation
3. Space-saving integration
| Specifications | Spes | Rated current | Contact resistance | Life cycles | Travel | Trip force | Request Samples |
| Servo Controller Membrane Switch Panel - BSD-5010-R5 |  |
35VDC，100mA，1W | 10--500Ω | Flat type ≥5,000,000 Tactile type ≥1,000,000 | Flat type 0.1~0.5mm Tactile type 0.6~1.5mm | Flat type 60g~300g(2~100Z) Tactle type 150g--400g(6--140Z） |
Request Samples
|
