16 speed rotary encoder switch 6p vertical surface mount rotary dip switch SD-R7H3-10-16-DIP BONSDA

SD-R7H3-10 Rotary Encoder Switch, 10-Position 6-Pin Plug-In Rotary Switch, Domestic Rotary Encoder Switch

Product Characteristics

1. RATING : DC 24V 25mA；

2. CONTACT RESISTANCE : 100mΩ Max；

3. INSULATION RESISTANCE : 100MΩMin,100V DC；

4. DIELECTRIC STRENGTH : 250V AC / 1 Minute；

5. TRAVEL: 中心（CENTER）36.0°/360°；

6. OPERATING FORCE：200gf Max；

7. OPERATING TEMP:-30℃to+80℃；

8. STORAGE TEMP:-40℃to+85℃.

Online Message

After filling in your contact information, return to unlock the catalog and drawing download function.

Verification code*

Overview

1. Model: SD-R7H3-10

2. Positions: 10 positions/16 positions

3. Shaft: Shaft available

4. Package Type: 6-Pin Plug-In Dual Inline Package (DIP)

5. Specifications: 7.35mm x 7.35mm x 3.0mm base

6. Lifespan: ≥20000 Steps

7. Operating Force: 200gf Max

8. Origin: China

9. Functionality: Users rotate the shaft handle to the desired position, reflecting BCD coded output values.

10. Applications: Automotive, smart wearables, smart home, industrial control, power electronics, telecommunications, and many other fields.

Parameters

Specifications	Spes	Rated current	Contact resistance	Life cycles	Travel	Trip force	Request Samples
7.35mm x 7.35mm x 3.0mm		DC 24V 25mA	100mΩ Max	≥20000 Steps		200gf Max	Request Samples
